Description
Premium Ceramic Unidirectional Double-Sided Flap Disc engineered for stainless steel and hard metals. Its unique double-sided construction allows grinding and finishing from both sides of the disc, providing excellent versatility, performance and efficiency.
Designed for demanding applications including top and bottom chamfering, blending and grinding on both sides, fillet weld grinding, pipe deburring and inside corner grinding. The ceramic abrasive provides an aggressive cut and consistent performance on tough materials.
Available in 5″ and 7″ sizes with 40, 60, and 80 Grits. Different grit combinations can be used on each side, allowing multiple grinding and finishing operations with one disc.
Suitable for the following materials:
- Stainless Steel
- All Hard Metals
Shrink wrapped in 5s.
Specifications
| SIZES | 4 1/2" / 5" | TYPE: | T1F |
| ABRASIVE MATERIAL: | VSM Premium Ceramic | DENSITY: | Standard |
| GRITS: | 40 / 60 / 80 | COLOUR: | RED |
| BACKING: | Fiberglass | QUICK CHANGE | ZINC HUB |
| MAX RPM. (OD in inches - RPM) | 4" - 15,300 / 4 1/2" - 13,300 / 5" - 12,200 / 6" - 10,200 / 7"- 8,500 |
Item Numbers Packaging and Availability
For items not listed below please contact customer service. For some items minimum quantity and longer lead times apply.
| Item # | Size | Grit | Type | Pkg. Qty. | Availability |
| CUDS45041H | 4-1/2 x 5/8-11 | 40G | T1F | 5 | 1-14 DAYS |
| CUDS45061H | 4-1/2 x 5/8-11 | 60G | T1F | 5 | 1-14 DAYS |
| CUDS45081H | 4-1/2 x 5/8-11 | 80G | T1F | 5 | 1-14 DAYS |
| CUDS50041H | 5 x 5/8-11 | 40G | T1F | 5 | 1-14 DAYS |
| CUDS50061H | 5 x 5/8-11 | 60G | T1F | 5 | 1-14 DAYS |
| CUDS50081H | 5 x 5/8-11 | 80G | T1F | 5 | 1-14 DAYS |
Add SAFE LOC (Patented), Quick Change
SAFE LOC is a 5/8″-11 threaded attachment for flap discs. Available for 4 1/2″, 5″, 6″ and 7″ discs with any backing type.
For Item with SAFE LOC Quick Change add S to the end of Item with 7/8″ Arbor Hole. e.g. Item: Z5045049 with 7/8″ AH will become Z5045049S with 5/8″-11 SAFE LOC.
For Item with 5/8″-11 Zinc Hub add H to the of Item with 7/8″ Arbor Hole. e.g. Item: Z5045049 with 7/8″ AH will become Z5045049H with 5/8″-11 Zinc Hub.
